Module Connect

The interface made to measure
The Module Connect is the concept of a new type of plug-in connector for the connection of electrical cables, fibre optic cables and pneumatic hoses. As a cable connector, our modular connector is characterised by a space-saving, flat housing and is used wherever several or a large number of cables are to be plugged into the smallest possible space. The quick connector is concealable without additional coding. Convince yourself of our modular connector.

製品の数: 56

モジュールコネクト ケーブル4本用

多数のコネクタに代わる、オーダーメイド構成可能な 1つ のインターフェース
  • 5つのインターフェース/10のモジュールコネクト・プラグインコネクタのセット
お問合せ
出荷可能な1型式中:
1 は29営業日で出荷可能
購入はこちら

モジュールコネクト ケーブル3本用

多数のコネクタに代わる、オーダーメイド構成可能な 1つ のインターフェース
  • 5つのインターフェース/10のモジュールコネクト・プラグインコネクタのセット
お問合せ
出荷可能な1型式中:
1 は29営業日で出荷可能
購入はこちら

モジュールコネクト 固定部品

  • 壁や床に設置する取付ブラケットとして、またハウジング接続として
  • 柔軟な取付が可能
  • 固定用部品10個入りパック
お問合せ
出荷可能な1型式中:
1 は29営業日で出荷可能
購入はこちら

モジュールコネクト ダブルロック

  • モジュールコネクトハウジングの接続と固定
  • ダブルロック ×1
  • ねじ ×1
  • ナット ×1
お問合せ
出荷可能な1型式中:
1 は29営業日で出荷可能
購入はこちら

モジュールコネクト シングルロック

  • モジュールコネクトハウジングの接続と固定
  • シングルロック ×1
  • ねじ ×1
  • ナット ×1
お問合せ
出荷可能な1型式中:
1 は29営業日で出荷可能
購入はこちら

Module Connect housing 09140048101 / 09140008014 / 09140008013 / 09140048001

Available housing parts for the Module Connect.
お問合せ
出荷可能な4型式中:
4 は29営業日で出荷可能
購入はこちら

Module Connect bellows sealing insert 09140008100 / 09140008200 / 09140008300

Available sealing inserts for the Module Connect.
お問合せ
出荷可能な3型式中:
3 は29営業日で出荷可能
購入はこちら

Module Connect strain relief 09140008034 / 09140008033

Available strain relief for the Module Connect.
お問合せ
出荷可能な2型式中:
2 は29営業日で出荷可能
購入はこちら

Han EE® Quick Lock module 09140122632 / 09140122732

Number of contacts: 12, silver-plated
Electrical data: 10A / 250V
Connection type: Quick Lock connection
Conductor cross-section: 0.25 ... 1.5mm²
お問合せ
出荷可能な2型式中:
2 は29営業日で出荷可能
購入はこちら

Han DD® module 09140123102 / 09140123002

Number of contacts: 12
Electrical data: 10 A / 250V
Conductor cross-section: 0.14 ... 2.5mm²
Connection type: Crimp connection, Han ® D
お問合せ
出荷可能な2型式中:
2 は29営業日で出荷可能
購入はこちら

Han® DDD module 09140173001 / 09140173101

Number of contacts: 17
Electrical data: 10A / 150V
Conductor cross-section: 0.14 ... 2.5mm²
Connection type: Crimp connection, Han ® D
お問合せ
出荷可能な2型式中:
2 は29営業日で出荷可能
購入はこちら

Han DD® Quad module 09140423001 / 09140423101

Number of contacts: 42
Electrical data: 10A / 150V
Conductor cross-section: 0.14 ... 2.5mm²
Connection type: Crimp connection, Han ® D
お問合せ
出荷可能な2型式中:
2 は29営業日で出荷可能
購入はこちら

Han® High Density module 09140253001 / 09140253101

Number of contacts: 25
Electrical data: 4 A / 50 V
Conductor cross-section: 0.08 ... 0.52mm²
Connection type: Crimp connection, D-Sub
お問合せ
出荷可能な2型式中:
2 は29営業日で出荷可能
購入はこちら

5 A - D-Sub - crimp contacts pin

5A - D-sub - crimp contacts pin (gold-plated or HMC gold-plated) (PU: 100 pieces)
お問合せ
出荷可能な6型式中:
6 は29営業日で出荷可能
購入はこちら

5 A - D-Sub - crimp contacts bushing

5A - D-sub - crimp contacts socket (gold-plated or HMC gold-plated) (PU: 100 pieces)
お問合せ
出荷可能な6型式中:
6 は29営業日で出荷可能
購入はこちら
